Combined Therapy 1 MHz Ultrasound and 4 Channel TENS Machine : STRIVE

TENS

Channel                       Four independent output

Wave Form                 Biphasic Rectangular Wave

Pulse Frequency          2Hz, 20Hz, 40Hz, 80Hz, 100Hz, 150Hz

Pulse Mode                 Continuous, Burst, PWM, Surge, Sweep, Mixed

Pulse Amplitude          0 – 80 mA/Channel

Pulse width                 150 micro sec. (except PWM Mode)

Timer                           0 – 90 min

ULTRASONIC

Emission Frequency    1 MHz ±10%

Modes                         Continuous

PULSE 1, PULSE 2 & WAVE

Ultrasound Power       2.5 W/cm2 in continuous

3.5 W/cm2 in pulsed

Dimensions                 38 x 28 x 12.5 cm (LXBXH)

Fuse                             1 Amp

Power Source              90 to 240V AC 50/60Hz, SMPS supply

Weight                        1.2 Kg. /unit

ULTRASONIC DOSE Modes

Continuous:     0 to 2.5 Watts/cm2

Pulse 1:            Pulse frequency variable from 1Hz, 10 Hz, 50 Hz & 100 Hz

and intensity from 1 to 3.5 Watts /cm2

Pulse 2:            Pulse ratio variable from 1:2, 1:4, 1:7 & 1:9 ratio

and intensity from 1 to 3.5 Watts /cm2

Wave:              Pulse intensity will vary automatically from 0.5 W/cm2 to

Highest value set from 0.5 W/cm2 to 3.5 Watts /cm2
